Broadcom 3ware 9750-8i LSI00214 PCIe2.0 x8 8-Port Internal 6Gb/s SATA/SAS Hardware RAID Controller
¥1,314.00
促销价
¥1,314.00
常规价格
跳至产品信息
Broadcom 3ware 9750-8i LSI00214 PCIe2.0 x8 8-Port Internal 6Gb/s SATA/SAS Hardware RAID Controller
¥1,314.00
促销价
¥1,314.00
常规价格
Basic Parameter Table
| Item | Details |
|---|---|
| Brand | Broadcom (3ware series) |
| Model | 9750‑8i |
| Board PN | LSI00214 |
| Bus Interface | PCI‑E 2.0 x8 |
| Port Layout | 8 internal ports, zero external ports |
| Connectors | 2 × internal SFF‑8087 |
| Transfer Speed | 6Gb/s SATA / SAS |
| Cache Feature | Large onboard cache chip, no optional CacheVault flash power backup module |
| Firmware Mode | Native IR hardware RAID; cross-flashable to pure IT pass-through firmware for NAS/ZFS/unRAID |
| Cooling | Large white dense passive fin heatsink, fanless silent design |
| Condition | Factory New Sealed |
| Stock Status | In Stock |
| Lead Time | Deliver within 2 business days |
| Warranty | 3-Year Global Warranty |
| Unit Price | $185.00 |
Core Product Features
- Mid-range internal-only 3ware hardware RAID card, independent RAID acceleration chip with large onboard cache, supports full enterprise hardware RAID redundancy schemes for internal multi-disk arrays.
- Dual SFF-8087 internal connectors support up to 8 internal 6G SAS/SATA hard drives/SSDs; PCIe2.0 x8 high-speed bus fully meets high-load multi-disk array bandwidth requirements.
- Dual available firmware modes:
- IR RAID Mode: Native hardware RAID 0/1/5/6/10/50/60, hardware-level disk redundancy and write cache acceleration, for enterprise file servers requiring data fault tolerance.
- IT Pass-through Mode: Can reflash pure IT firmware, OS fully controls each disk independently, compatible with ZFS RAID-Z, unRAID, FreeNAS storage systems.
- Oversized white passive heatsink ensures stable 24/7 uninterrupted silent operation for rack servers; full-height & low-profile mounting brackets included.
- Internal hard drive hot-swap supported under both RAID and IT firmware modes, all internal storage devices can be hot-replaced without shutdown.
- Cost-effective 8-port internal RAID/HBA dual-purpose card, larger cache and more ports than 4-port 9750-4i, mainstream choice for medium multi-bay enterprise RAID storage and 8-bay home NAS after IT flashing.
Application Scenarios
- IR RAID deployment: Medium enterprise 8-disk internal redundant file storage servers, office backup storage requiring hardware RAID protection.
- IT flashed deployment: 8-bay internal ZFS TrueNAS / unRAID media NAS, medium-capacity home lab multi-disk storage chassis.
- Not applicable: Mission-critical storage requiring power-failure cache protection (no CacheVault), external JBOD expansion (no external ports).
